CNC Grooving Insert DCGT1204R240-R1.7 -- Uncoated, for Aluminum.

CNC Grooving Insert DCGT1204R240-R1.7 -- Uncoated, for Aluminum.
CNC Grooving Insert DCGT1204R240-R1.7 -- Uncoated, for Aluminum. CNC Grooving Insert DCGT1204R240-R1.7 -- Uncoated, for Aluminum. CNC Grooving Insert DCGT1204R240-R1.7 -- Uncoated, for Aluminum.

Large Image :  CNC Grooving Insert DCGT1204R240-R1.7 -- Uncoated, for Aluminum.

Product Details:
Place of Origin: CHINA
Brand Name: Hanyuhaoyang
Model Number: DCGT1204R240-R1.7
Payment & Shipping Terms:
Minimum Order Quantity: ten PCS
Packaging Details: Tight packaging, multiple layers of wrapping
Delivery Time: It is determined according to the customer's order.
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: ten million PCS
Contact Now

CNC Grooving Insert DCGT1204R240-R1.7 -- Uncoated, for Aluminum.

Description
Model: DCGT1204R240-R1.7 Advantage: Improve Machining Accuracy And Enhance Processing Efficiency
Application Fields: Auto, Aero, Energy, Mach, Etc. Origin: China
Category: Custom - Made Model
Highlight:

machine tool CNC Grooving insert

,

cemented carbide CNC Grooving insert

,

R1.7 CNC Grooving insert

CNC Grooving Insert DCGT1204R240-R1.7 – Uncoated, for Aluminum
Product Overview

This series of inserts belongs to standard grooving inserts. For custom requirements, please contact our online customer service or leave your contact information for further assistance.

Inserts with HYB208 coating are suitable for machining difficult-to-machine materials except high-temperature alloys, while inserts with HY08 coating are designed for aluminum machining.

Difficult-to-machine materials include stainless steel, hardened steel, nodular cast iron, etc.

Industry Applications
Industry Field Specific Scenarios / Typical Components
Automotive Manufacturing
  • Engine: piston ring grooves, cylinder block oil grooves, valve retainer grooves
  • Transmission: synchronizer hub grooves, clutch pressure plate grooves, valve body oil grooves
  • Drivetrain: driveshaft snap ring grooves, bearing locating grooves, spline grooves
Aerospace
  • Engine components: turbine disk tenon grooves, compressor blade locking grooves
  • Structural parts: landing gear shaft snap ring grooves, titanium alloy joint sealing grooves
  • Fasteners: high-lock bolt ring grooves, self-locking nut internal grooves
Mold Manufacturing
  • Injection molds: cooling channel grooves, ejector plate grooves, slider guide grooves
  • Die-casting molds: overflow grooves, vent grooves, core-pulling mechanism grooves
  • Stamping dies: guide grooves, spring mounting grooves, wedge slide grooves
General Machinery
  • Hydraulics/Pneumatics: valve body flow channels, piston rod sealing grooves, cylinder oil grooves
  • Bearing industry: bearing cage grooves, raceway locating grooves
  • Construction machinery: pin snap ring grooves, track link connecting grooves
Energy Equipment
  • Wind power: gearbox oil grooves, main shaft locking grooves, yaw ring gear grooves
  • Oil & gas drilling: drill pipe joint grooves, sucker rod ring grooves, valve sealing grooves
Medical Devices
  • Orthopedic implants: bone plate locking grooves, intramedullary nail locking hole grooves
  • Surgical instruments: stapler cartridge grooves, forceps jaw teeth grooves
  • Dental: implant thread grooves, abutment locating grooves
Electronics / Precision Instruments
  • 3C products: mobile phone mid-frame antenna grooves, heat sink slots, housing sealing grooves
  • Precision instruments: sensor locating grooves, optical lens adjustment slots
Frequently Asked Questions
Q: Are you the original manufacturer of the inserts?
A: Yes, we are the original factory for both standard and non-standard inserts with a 14-year entrepreneurial history. We have our own production lines, as well as design and sales teams.
Q: How long is your delivery time?
A: It is determined according to the customer's order. You can communicate the details directly with the customer service on our website.
Q: What is the best way to contact you?
A: Contact us via email, WhatsApp, WeChat (ID: hanyuhaoyangtools), phone (+86 13880606307), or live chat.
CNC Volute Cutting Insert HY43X15X7.5XR3-17° – High-Strength Machining Tool
